出色的光譜均勻度
是BER測試和係統驗證的理想之選
集成的功率監測選件（在單模和多模型號上），
可輕鬆實現功率設置和更出色的穩定性
為全天候生產應用設計，隻需要很少的維護
快速設置，可優化效率 。
Specifications No power monitoring With power monitoring
1. Single-mode configuration
Fiber type (µm) 9/125 9/125
Wavelength range (nm) 1250 to 1650 1250 to 1650
Maximum attenuation (dB) ≥ 65 ≥ 65
Insertion Loss dB Typical 1.0 Maximum 1.5/2.2
Resolution of attenuation setting (dB) 0.002 0.002
Attenuation linearity (dB) ±0.1 ±0.1
Repeatability of attenuation (dB) ±0.01 ±0.01
Power meter linearity (dB) ±0.03
Power Setting Repeatability (dB) ±0.035
Return Loss (dB) 60
Maximum Input Power (dBm) 23
Multimode Configuration
Fiber Type (µm) 50/125, 62.5/125 50/125, 62.5/125
Wavelength Range (nm) 700 to 1350 700 to 1350
Maximum attenuation (dB) (typical) ≥ 60 ≥ 60
Attenuation setting resolution (dB) 0.002
Attenuation linearity (dB) ±0.1
Return Loss (dB) (typical) 40
Maximum Input Power (dBm) 20
Weight 0.67 kg
