1.Test frequency support range: 2MHz-4400MH/6000MHz
2.Frequency resolution: 1Hz
3.Output level: >10dB
4. Support 5 kinds of data points: 130, 259, 517, 1033, 2056
5. Interference rejection: +10 dBm (within ±10 kHz) +25 dBm (>1.0 MHz)
6. VSWR test range: 0-65
1. With VSWR, return loss, cable loss, fault locations (return loss), fault locations (VSWR), Smith chart
2. Can automatically PASS/FALL analysis
3. With PC software, test data can be analyzed and report output
4. Double battery slots, can last 8 hours
1. Base station RF unit, cable routine maintenance
2.Leakage cable and antenna VSWR acceptance test (refer to GB 50382-2016 "Quality Acceptance Specification for Urban Rail Transit Communication Engineering")
3.Leaky cable and antenna fault locations
